| TECHNICAL DATA |
|
| air convection |
forced |
| chamber capacity [l] |
70 |
| working capacity [l] |
55 |
| controller |
microprocessor PID |
| display |
7" full colour touch screen |
| TEMPERATURE |
|
| temperature range [°C] |
0...+15 |
| temperature resolution every … [°C] |
0,1 |
| temperature fluctuation at 4°C [+/-°C]* |
0,4 |
| temperature variation at 4°C [+/-°C]* |
0,7 |
| temperature protection |
class 3.2 to DIN 12880 |
| CHAMBER |
|
| door type |
solid / glass or double (option) /4/ |
| interior |
|
| P Smart PRO |
acid-proof stainless steel to DIN 1.4301 |
| PS Smart PRO |
acid-proof stainless steel to DIN 1.4301 |
| housing |
|
| P Smart PRO |
powder coated sheet |
| PS Smart PRO |
stainless steel polished |
| overall dims [mm] /1/ |
|
| width A |
550 |
| height B |
660 |
| depth C |
680 |
| internal dims [mm] |
|
| width D |
430 |
| width D' |
470 |
| height E |
430 |
| depth F |
300 |
| depth F' |
360 |
| |
| shelves (standard | max) |
2 | 2 |
| max shelf workload [kg] /2/ |
10 |
| max unit workload [kg] |
20 |
| weight [kg] |
37 |
| ELECTRICAL PARAMETERS |
|
| voltage** |
230V 50-60Hz |
| nominal power [W] |
250 |
| refrigerant |
R1234ze / GWP=1 |
| warranty |
24 months |
all the above technical data refer to standard units (without optional accessories)
* - fluctuation measured in centre of the chamber; in space, variation (K) calculated for chamber as:
K= +/- (T average max. - T average min. ) / 2
** - other power supplies on request
1 - depth doesn't include 50 mm of power cable, the width does not include the 20 mm of rubber plug
2 - on uniformly loaded surface
3 - reinforced shelf
4 - additional internal glass door
